JUAL GENSET IWATA 360Kw MURAH

Harga Normal:

~~Rp.735.672.000~~

harga anda:

Rp.425.550.000 (Anda hemat Rp.310.122.000)

SKU:

GENSET IWATA 360Kw

Berat:

4.150,00 KGS

Pengiriman:

Rp.900.000 (biaya pengiriman tetap)

Deskripsi Produk

SPESIFIKASI GENSET

Model

: IW360WS

Frequency

: 50Hz

Rated Power

: 360kw

Max Power

: 400kw

Rated Voltage (V)

: 230/400 3Ph

Rated current (A)

: 649.8

Rated Speed (r/min)

: 1500

Starting Mode

: 24V

Fuel Tank Capacity (Liter)

: 1000

Opr. time on single tank fuel

: 12.5 Hours

Noise level (dB(A)/ 7m)

: 85

Dimension L.W.H. (mm)

: 4800x1900x2400

Net weight (kg)

: 4150kgs

Engine Model

: W269TAD41

Engine Manufacturer

: IWATA

Bore*Stroke (mm)

: 138*150

Displacement (L)

: 26.9

12hrs Power (kw)

: 418

Fuel Cons. at Full Load L/h 80L/h

Engine Type Water Cooled, 4-stroke, Direct injection

Cylinder

: No. 12

Compression Ratio

: 14.7:1

Starting Motor (V-KW)

: 24V-4KW

Charging Alternator (V-W)

: 28V-500W

Circulated type 3 Phase, 4 Wires, Y type Connection

Excitation Mode Brushless Self-Excitation and Constant Voltage (AVR)

Power factor cos

: 0.8 (lag)

Pole Number

: 4

Insulation

: H

Overexcitation Protection

: IP23

Voltage Regulator

: AVR SX460

Voltage Regulator NL-FL

: ± 5%

Pengiriman paket barang apabila dikirim pake kurir adalah dari singaporenamun barang bisa langsung diambil di darat gudang toko kami di batamPesan via website, prosesnya 2-4 hari barang tersedia di gudang tokolangsung datang untuk pengambilan, dan pembayaran adalah ditempat saat pengambilan.
